Noctua NH-U12A

158 mm
Price in EUR including VAT, free shipping
84Ratings
BrandMore from Noctua
Delivered Mon, 30-12
6 items in stock

Product details

The 120mm NH-U12A premium cooler is the latest, fifth generation of Noctua's award-winning NH-U12 series. To get even more performance out of the 120mm form factor, it is equipped with two copies of the
very quiet flagship fan NF-A12x25 PWM and has a completely newly developed heat sink with 7 heatpipes and more surface area for even better heat dissipation. In this way, the NH-U12A can compete with many 140mm CPU coolers, but at the same time offers the case and PCIe compatibility of the 120mm class. The all-round high-quality complete package is rounded off by the proven SecuFirm2 multi-socket mounting system, Noctua's renowned NT-H1 quality thermal compound and a full 6-year manufacturer's warranty. Its first-class cooling performance, excellent compatibility and excellent running smoothness make the NH-U12A a genuine premium solution for the highest demands.

Key specifications

Socket
AM2,
AM2+,
AM3,
AM3+,
AM4,
AM5,
FM1,
LGA 1150,
LGA 1151,
LGA 1155,
LGA 1156,
LGA 1200,
LGA 1700,
LGA 2011,
LGA 2011-v3,
LGA 2066
Height (with fan)
158 mm
Diameter
120 mm
power connector
4-pin PWM
Number of fans
2 x
Item number
10847172

General information

Manufacturer
Noctua
Category
CPU coolers
Manufacturer no.
NH-U12A
Release date
8.7.2020
External links
Manufacturer's site (de)

Colour

Colour group
Brown
Exact colour description
Beige,
Bronze,
Silver

Cooler properties

CPU cooler design
Single Tower
Fan type
Standard
Processor socket
AM2,
AM2+,
AM3,
AM3+,
AM4,
AM5,
FM1,
LGA 1150,
LGA 1151,
LGA 1155,
LGA 1156,
LGA 1200,
LGA 1700,
LGA 2011,
LGA 2011-v3,
LGA 2066
Cooler mounting
Backplane
Supported fan sizes
120mm

Heat sink properties

Number of heatpipes
7
Diameter heat pipe
6 mm
Number of cooling fins
50
Materials radiator core
Copper
Material cooling fins
Aluminium

Fan dimensions

Diameter
120 mm
Length
120 mm
Width
120 mm
Height
25 mm
Weight
230 g

Fan properties

Number of fans
2 x
Maximum mountable fan
2
Max. Speed
2000 RPM
Airflow
102.10 m³/h
Static pressure
0.23 Pa
Max. noise level
22.60 dB
LED colour
without LED

Connections

power connector
4-pin PWM

Power supply

Power consumption
3.36 W
Voltage
12 V

Scope of delivery

Scope of delivery
3-pin adapter,
4-pin adapter,
Installation material,
Manual,
Thermal grease,
Y-split cable

Product dimensions

Width (with fan)
125 mm
Length (with fan)
112 mm
Height (with fan)
158 mm
Weight
1220 g

Package dimensions

Length
22.20 cm
Width
18.10 cm
Height
17.30 cm
Weight
1.85 kg
